ONE-WAY DOUBLE RING END 72 TEETH RATCHET WRENCH

ONE-WAY DOUBLE RING END 72 TEETH RATCHET WRENCH
ONE-WAY DOUBLE RING END 72 TEETH RATCHET WRENCH
ARW-13M-SERIES
ONE-WAY DOUBLE RING END 72 TEETH RATCHET WRENCH
Share To Line Share To Facebook Share To Twitter mail
Inquiry
Product Description

ARW-13M0608-HT, ARW-13M0810-HT, ARW-13M1011-HT, ARW-13M1012-HT,
ARW-13M1213-HT, ARW-13M1416-HT, ARW-13M1418-HT, ARW-13M1618-HT,
ARW-13M1719-HT, ARW-13M2022-HT



proimages/product/ARW-13Mz1.png

  • MIRROR FINISHED
  • FLAT PANEL: ALL DROP FORGED FROM CHROME VANADIUM STEEL
  • DIN 7444

ITEM NO. SIZE
(MM)		 L
(MM)		 A
(MM)		 B
(MM)		 C
(MM)		 D
(MM)		 E
(MM)		 F
(MM)		 W
(MM)
ARW-13M0608-HT 6 × 8 130.4 17.4 20.9 7.4 7.4 3.4 8.6 10.3
ARW-13M0810-HT 8 × 10 130.4 17.4 20.9 7.4 7.4 3.4 8.6 10.3
ARW-13M1011-HT 10 × 11 144.4 20.9 22.9 7.4 8.7 3.6 10.3 11.3
ARW-13M1012-HT 10 × 12 144.4 20.9 22.9 7.4 8.7 3.6 10.3 11.3
ARW-13M1213-HT 12 × 13 166.0 23.4 24.9 8.7 8.7 4.0 11.5 12.3
ARW-13M1416-HT 14 × 16 181.4 27.4 30.4 8.7 10.3 4.5 13.5 15.0
ARW-13M1418-HT 14 × 18 181.4 27.4 30.4 8.7 10.3 4.5 13.5 15.0
ARW-13M1618-HT 16 × 18 205.9 30.4 33.9 10.3 10.3 5.0 15.0 16.8
ARW-13M1719-HT 17 × 19 224.4 31.9 34.4 10.3 10.3 5.2 15.5 17.0
ARW-13M2022-HT 20 × 22 224.4 31.9 34.4 10.3 10.3 5.2 15.5 17.0

proimages/product/ARW-13M.png





Contents:

  • 1 PC ONE-WAY DOUBLE RING END 72 TEETH RATCHET WRENCH

  • PACKING: PLASTIC HANG TAG + LABEL + COLOR BOX
